18KG25TE-DO Deck Over Tilt Trailer
Model: 18KG25TE-DO Tilt Trailer
Weight: 5,100#
Description: 20' Tilt 5' Stationary
�
�
�
Specifications
| G.V.W.R. | 18,000 # | Axles | 2-8K Dexter Oil Bath | ||
| G.A.W.R. (each axle) | 8,000 # | Suspension | Slipper Spring | ||
| Coupler | Gooseneck | Tires | 215 75R 17.5 | ||
| Safety Chains | High Tensile Safety Chains | Wheels | 17.5X8 | ||
| Jack | Dual 12K Jacks | Floor | Standard Oak/Treated Pine | ||
| Neck | 10" I Beam 16# per Foot | Lights | LED�Lights / DOT�Specs. | ||
| Frame | 10" I�Beam 19 # per Foot | Finish (prep) | 2 Coats Primer | ||
| Crossmembers | 3" Channel 16" O.C. | Finish | Paint including underneath | ||
| Side Rails | 8" Channel | Paint | 2 Coats |
�
Standard Features
- Oak / Treated Pine Decking
- Rub Rails and Stake Pockets
- Recessed Deck Straps
- Sealed wiring harness
- LED�Rubber Mounted sealed beam lights
- 2 year warranty
- Dexter Axles
- 102" Wide
- Slipper Spring Suspension
- Electric Brakes on All Axles
- Radial Tires
- Meets and Exceeds D.O.T. Regulations
- Primed and Painted underneath
�
Available Options: on most models
- Cargo Winch and Straps
- Additional Deck Length
- Deckover Goose Neck
- Cleated Rear Deck (Tilt)
- Spare Tire and�Wheel
- Power Tilt
- Steel Deck
- Any other custom needs
